Bypass Switches
Chilli Pro dimmers are available in variants with bypass switches per
channel. With bypass variants, a dedicated bypass switch per channel
is provided on the front of the Chilli Pro.
When a bypass switch is pressed in for a channel, the supply to the channel output bypasses the dimming circuitry,
and is fed from the mains supply. This therefore allows you to connect non-dimmable loads to this channel's output,
such as moving lights or LED fixtures.
Non-dimmable loads should NOT be connected without the bypass switch being activated. Powering non-
dimmable loads directly from the dimming circuitry can cause damage to both the load device and Chilli Pro.
Zero 88 - Chilli Pro - Page 48 of 60 Printed: 23/03/2021 09:13:40 ES
