Zerotech DOBBY User Manual

10
零度智控（北京）智能科技有限公司
Flight
Data


DOBBYwillbegintorecordflightdatafromthemomentyouturniton.Itwillstoprecordingthedataoncethe
powersourceisturnedoff.Thedatafilewillbesenttoyourmedialibrary.Thenameofthefilewillbethetime
whenthedatawasrecorded.Youcandownloadthefiledirectlytoyourmobiledevicefromtheapp.
Propell
er
DOBBYhas4sets(8blades)of3inchlongfoldablepropellerblades.Thebladesarealreadyfitted,usersonlyneedto
expandthejib‐armsbeforeflight.Whenyou’redoneflying,foldthejib‐armsandpropellersintothebaseofthe
dronetopreventdamagingthem
.

Thepropellersbladeshaveeither‘A’or‘B’onthetoptoindicatein
whichdirectiontheyspin,asshownonthefirstpicture
ontheright.
ReplacingthePropellerBlades
Old propeller blades must be replaced with new blades
that spin in the same direction. Propeller blades with an
‘A’ on top must be replaced with new blades that also
havean‘A’,oneswitha‘B’ontopmustbereplacedwith
new blades that have a ‘B’
, as in the first picture on the
right.

Methodforreplacingthepropellerblades:Useascrewdrivertoloosen
thescrews,removetheoldpropellerbladesandfitthenewon
propellerbladesontothebase,asshowninthesecondpicture
ontheright.
Pleaseensurethatthepropelleristightlyscrewedin,topreventagainstthescrewscomingloose
andthepropellersbladesfallingoffduringflight.Itwillneedtoberetightenedafterevery10hours
offlight.
Battery


ThebatteryisdesignedspecificallyforusewithDOBBY.Ithasacapacityratingof970mAhandanominal
voltageof7.6V.Thebattery’scharacteristicsareasfollows:

Zerotech DOBBY Specifications

General

Type	Quadcopter
Easy to use	Yes
Product color	White
Construction type	Ready-to-fly (RTF)
Maximum speed	- m/s
Number of rotors	4 rotors
Maximum flight time	9 min
Maximum weight capacity	- kg
Maximum wind resistance	7.7 m/s
Horizontal hover accuracy	0.3 m
Maximum operating distance	100 m
Megapixel	13 MP
Sensor type	CMOS
Video resolutions	320 x 240, 640 x 480, 1280 x 720, 1920 x 1080 pixels
Maximum frame rate	30 fps
Optical sensor size	1/3.06 \
Supported video modes	1080p
Image formats supported	JPG
Video formats supported	H.264, MP4, MPEG4
Maximum image resolution	4208 x 3120 pixels
Field of view (FOV) angle	75 °
Internal memory	16 GB
Memory card slot(s)	-
Operating temperature (T-T)	0 - 40 °C
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
Battery voltage	7.6 V
Battery capacity	970 mAh
Number of batteries supported	1
Operating frequency	2400, 5000 MHz
Moving control functions	Backward, Downward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	145 mm
Width	135 mm
Height	36.8 mm
Weight	199 g
