Your Mobility Scooter
The Zip’r Roo series mobility scooter consists of the following major components listed in the
diagram below.
Tiller Console:
The tiller console houses all controls needed to drive your mobility scooter, including the key
switch, throttle control lever, horn button, speed adjustment dial, headlight switch, battery level
indicator and troubleshooting LED indicator.
PROHIBITED! Do not expose the tiller console to moisture. In the event that the tiller
console does become exposed to moisture, do not attempt to operate your mobility
scooter until the tiller console has dried thoroughly.
Horn Button
This button activates a warning horn. In order for the horn to sound your mobility scooter must
be turned on. Use of the warning horn may prevent accidents or injury.
Simple & Intuitive Control Stack
Horn
Adjustable Speed Knob
Headlight Switch
Forward
Reverse
Battery Indicator
Ignition Switch
