Installation instructions & user manual
T210023 v1.02 NOV 2018 - ZIP AP430S-AP4100S
Technical support
Tel: 0345 6 005 005 email: service@zipindustries .co.uk www.zipwater.co.uk
Electrical wiring diagram
1
2
4
5
3
N L
230V AC
REF DESCRIPTION
1
Connection terminal
2 Thermal cut-out
3 Electronic regulator
4 Electrical heating element
REF DESCRIPTION
5 Temperature sensor
L Live conductor
N Neutral conductor
Earthing conductor
Fig. 6
