Zte MF920U User Manual

5
Blue
blinking
You have new messages or
the message storage is
full.
Light off There is neither an unread
message nor a new
message.
Network
Red The device is in error
status.
 The device is not
registered to the
mobile network.
 There is no micro-SIM
card inserted.
 There is no network
service available.
Green
solid
The device is registered to
the 2G/3G mobile
network.
Green
blinking
The device is connected to
the 2G/3G mobile network
and data is being
transferred.
Blue solid The device is registered to
the 4G LTE network.

Zte MF920U Specifications

General

Ethernet WAN	No
Device type	Cellular network router
Product color	White
Built-in display	Yes
Wi-Fi frequency	2.4 GHz
Data network	LTE
USB port type	Micro-USB
Battery capacity	2000 mAh
Power source type	Battery
Power consumption (typical)	4 W

Weight and Dimensions

Depth	14.38 mm
Width	105.6 mm
Height	63.8 mm
Weight	102 g
