Page 22 of 23
Don’t use the Wi-Fi hotspot immediately after a sudden temperature change eg
from an air conditioned environment to high temperature and humidity outside.
In such cases there could be condensing moisture inside the Wi-Fi hotspot
which can cause internal damage. Unplug the Wi-Fi hotspot and leave it for 30
minutes before use.
Always handle the Wi-Fi hotspot with care. Be careful not to drop or bend the
device.
There are no user serviceable parts. Unauthorised dismantling or repair will void
the warranty.
The battery will not be charged above 45C.
RF SAFETY INFORMATION
The wireless device has an internal antenna. For optimum performance with
minimum power consumption do not shield the device or cover with any object.
Covering the antenna affects signal quality and may cause the Wi-Fi hotspot to
operate at a higher power level than needed.
RADIO FREQUENCY ENERGY
The wireless device is a low-power radio transmitter and receiver. When switched
on it intermittently transmits radio frequency (RF) energy (radio waves).
The transmit power level is optimized for best performance and automatically
reduces when there is good quality reception.
Maximum power is only used at the edge of network coverage so under most
circumstances the power output is very low.
Under poor network conditions the Wi-Fi hotspot transmits at a higher power level
and may get hot.
SPECIFIC ABSORPTION RATE (SAR)
The wireless device is designed to be used in close proximity to the body. We
declare that the product detailed in this manual, and in combination with our
accessories, conform with the essential requirements of The Radio
Communications Standard (Electromagnetic Radiation Human Exposure) 2003 and
the Australian Communications and Media Authority Section 376 of the
Telecommunications Act 1997 when used at a distance of not less than 5mm from
the body.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Zte OPTUS MF920V and is the answer not in the manual?

Zte OPTUS MF920V Specifications

Network IconNetwork
4G LTE bands700, 1800, 2300, 2600 MHz
3G UMTS bands900, 2100 MHz
GSM bands900, 1800 MHz
Data Rates IconData Rates
4G download speedsup to 150 Mbps
3G DC-HSPA+ mode speedup to 42 Mbps
Wi-Fi standard802.11 a/b/g/n, 2x2 MIMO, 2.5GHz
Power IconPower
voltage5 V
resting current100 mA rms
max current500 mA rms
Operating Environment IconOperating Environment
operating temperature-5ºC to +45ºC
battery capacity2000 mAh
charge time with chargerup to 3 hours
Weight and Dimensions IconWeight and Dimensions
dimensions105.6 x 63.8 x 14.38 mm
weight100 g
