Chapter1Overview

BackPanel

Figure1-2showsthebackpanel.

Figure1-2BackPanel

Table1-3liststheinterfacesandbuttonsonthebackpanel.

Table1-3InterfacesandButtonsontheBackPanel

Interface/ButtonDescription

LAN1-LAN4RJ-45LANinterface,connectstothelocal

networkthroughtheRJ-45networkcable

POTS1POTS2RJ-11telephoneinterface,connectstothe

telephonethroughtheRJ-11telephonecable

USBUSBinterface,connectstoastoragedeviceor

printerthathasaUSBinterface

UPSSecondarypowermonitoringinterface

POWERPowersocket,connectstothepoweradapter,12

VDC

WPSWPSaccessswitch

WLANWLANbutton,toenableordisableWLAN

RESETWhenthedeviceispoweredON,pressthebutton

formorethan5secondstorestorethefactory

defaultsettings.

SidePanel

ThesidepanelhasanSC/APCsingle-modeberinterface,implementingtheservices

providedbytheISPinPONaccessmode.ItconnectstotheGPONinterfaceofZXA10

F660throughanSC/APCsingle-modeber.Figure1-3showsthesidepanel.

1-5

SJ-20110718111034-001|2011-07-18(R1.0)ZTEProprietaryandCondential
