ZWO ASI2600 Series User Manual

ASI2600 Manual
11
5.7 Analog to Digital Converter (ADC)
The ASI2600 camera has a built-in 16bit ADC. 12bit ADC mode for output will be used when we
do hardware Bin, this camera also supports custom ROI partial readout mode, with faster frame
rate at small ROI resolutions.
Please see below attached different frame rates under different resolutions on USB3.0 and USB2.0
of ASI2600 in 16bit mode.
Resolution
16Bit ADC
USB2.0
USB3.0
6248*4176
0.83fps
3.51fps
4096*3072
1.72fps
4.75fps
3840*2160
2.61fps
6.71fps
1920*1080
10.43fps
13.13fps
1280*720
19.29fps
19.29fps
640*480
28.06fps
28.06fps
320*240
51.44fps
51.44fps

ZWO ASI2600 Series Specifications

General

Sensor Type	CMOS
Sensor Model	Sony IMX571
Cooling Delta	35°C below ambient
USB Interface	USB 3.0
ADC	16-bit
Dynamic Range	14 stops
Weight	700g
Sensor Size	APS-C
Pixel Size	3.76 μm
Quantum Efficiency	80%
Full Well Capacity	50, 000e-
Shutter Type	Rolling shutter
Operating Temperature	-5°C
Dimensions	90mm
