ACH 500 Programming Manual 6-1
Chapter 6 – Parameters
ACH 500 Parameter
Menus
This chapter explains the function of each parameter in the ACH 500, and the
valid selections for each parameter. Figure 6-1 shows the process of accessing
the ACH 500 Parameter Menus.
Figure 6-1 Parameter Menu Selection
ACH 500 Parameters
The ACH 500 parameters are divided according to function into four Mains
and 19 Groups. Operating Data parameters and Start-up Data parameters are
not accessed through Mains or Groups. Refer to Chapter 3 – Start-up Data
and Chapter 4 – Control Operations in this manual for more information on
Operating Data parameters.
40.2 PUMP & FAN CONTROL
40.1 PI-CONTROL
30.4 INFORMATION
30.3 SUPERVISION
30.2 AUTOMATIC RESET
30.1 FAULT FUNCTION
20.5 CRITICAL FREQUENCIES
20.4 MOTOR CONTROL
20.3 ACCEL/DECEL
20.2 START/STOP
20.1 FREQ/CURRENT LIMITS
10.8 EXT COMMUNICATION
10.7 ANALOG OUTPUTS
10.6 RELAY OUTPUTS
10.5 ANALOG INPUTS
START-UP DATA
C APPLIC.
RESTORE
D Supply Voltage
20 PARAMETER LOCK
.
.
.
.
30 PROTECTION
PARAMETERS
10 CONTROL
CONNECTIONS
10.4 SYSTEM CONTR INPUTS
10.3 PRESET SPEEDS
10.2 EX REFERENCE SELECT
10.1 START/STOP/
DIRECTION
20.3.8 DECEL REF2 TIME
20.3.7 ACCEL REF2 TIME
20.3.6 DECEL TIME 2
20.3.5 ACCEL TIME 2
20.3.4 DECEL TIME 1
20.3.3 ACCEL TIME 1
20.3.2 ACC/DEC RAMP SHAPE
20.3.1 ACC/DEC 1 OR 2 SEL
OPERATING DATA MAIN LEVEL GROUP LEVEL
PARAMETER LEVEL
1 OUTPUT FREQ.
2 MOTOR SPEED
PARAMETERS
20 DRIVE
A LANGUAGE
APPLICATION
1 HVAC
MACROS
2 FLOAT PT.
3 HVAC – PI
4 P&F AUTOM.
.
B APPLICATION
.
.
.
.
.
.
.
40 APPLICATION
PARAMETERS
