ABB ACQ580-01 User Manual

10
R1-
R4
R5
R6-
R9
EN
DA
DE
ES
FI
FR
IT
NL
PL
PT
RU
SV
TR
ZH
 U
N
= 400 V
 U
N
= 480 V
Type
ACQ580
-01-
Input
rating
Output ratings Heat
dissipation
Air flow Frame
size
Max.
current
Nominal use
I
1
I
max
I
N
P
N
A A A kW W m
3
/h
3-phase U
N
= 400 V
02A7-4 2.6 3.2 2.6 0.75 69 43 R1
03A4-4 3.3 4.7 3.3 1.1 78 43 R1
04A1-4 4.0 5.9 4.0 1.5 87 43 R1
05A7-4 5.6 7.2 5.6 2.2 113 43 R1
07A3-4 7.2 10.1 7.2 3.0 127 43 R1
09A5-4 9.4 13.0 9.4 4.0 165 43 R1
12A7-4 12.6 15.3 12.6 5.5 237 43 R1
018A-4 17.0 22.7 17.0 7.5 265 101 R2
026A-4 25.0 30.6 25.0 11.0 416 101 R2
033A-4 32.0 44.3 32.0 15.0 514 179 R3
039A-4 38.0 56.9 38.0 18.5 570 179 R3
046A-4 45.0 67.9 45.0 22.0 709 179 R3
062A-4 62 76 62 30 957 134 R4
073A-4 73 104 73 37 1230 134 R4
3AXD00000586715.xls L
Type
ACQ580
-01-
Input
rating
Output ratings Heat
dissipation
Air flow Frame
size
Max.
current
Nominal use
I
1
I
max
I
Ld
P
Ld
A A A hp W m
3
/h
3-phase U
N
= 480 V
02A7-4 2.1 2.9 2.1 1.0 45 43 R1
03A4-4 3.0 3.8 3.0 1.5 55 43 R1
04A1-4 3.4 5.4 3.5 2.0 66 43 R1
05A7-4 4.8 6.1 4.8 3.0 84 43 R1
07A3-4 6.0 7.2 6.0 3.0 106 43 R1
09A5-4 7.6 8.6 7.6 5.0 133 43 R1
12A7-4 11.0 13.7 12.0 7.5 174 43 R1
018A-4 14.0 19.8 14.0 10.0 228 101 R2
026A-4 21.0 25.2 23.0 15.0 322 101 R2
033A-4 27.0 37.8 27.0 20.0 430 179 R3
039A-4 34.0 48.6 34.0 25.0 525 179 R3
046A-4 40.0 61.2 44.0 30.0 619 179 R3
062A-4 52 76 52 40 835 134 R4
073A-4 65 104 65 50 1024 134 R4
3AXD00000586715.xls L
