CHAPTER 2 – POWER ELECTRONICS AND CABINET FEATURES 42
2.4 Terminal compartment
The terminal compartment provides the terminals for the feeder and
motor cables and the ground bus for the termination of the ground
cable and the cable screens.
The cable entry is prepared in the factory for to the
cable entry configuration ordered:
• Top or bottom cable entry
• Type of entry plate
• For information on the type of cable
entry in the drive, see Appendix C –
Mechanical drawings.
• For further information, see 6.8 Cable
entries.
2-14 Terminal
compartment
