0 5 . PR OT EC T I O N F U N C T I O N S 43

Function

Setting range 0=Disabled 1=Enabled

Default value Enabled

Step value 1

Disabled during motor startup

Setting range 0=Enabled during motor startup 1=Disabled during motor startup

Default value 0

Step value 1

Trip reset mode

Setting range 1=Auto 2=Local 3=Remote 4=Remote and local

Default value 4

Step value 1

Thermal model

Setting range 0=Standard model 1=EEX e

Default value 0

Step value 1

TOL bypass

Setting range 0=Disabled 1=Enabled

Default value Disabled

T6 (standard mode)

Setting range 3-40sec

Default value 6sec

Step value 1

Cool coefficient

Setting range 1-10

Default value 4

Step value 1

Ia/In(Eexe mode)

Setting range 1.2-8.0

Default value 5.0

Step value 0.1

Te(Eexe mode)

Setting range 5-40sec

Default value 5sec

Step value 1sec

TOL alarm level

Setting range 60-100%

Default value 90%

Step value 1%

TOL trip level

Setting range 60-100%

Default value 100%

Step value 1%

TOL reset level

Setting range 10-60%

Default value 50%

Step value 1%

Ambient temperature

Setting range 0-80°C

Default value 40°C

Step value 5°C

—



''
