Connection ports
There are two connection ports available on MDx
panel. RJ11 port which locates on the back of the
panel connects to M10x main unit. A mini USB port
is available on the front for parameterization con-
nection.
A dedicated parameterization cable is required to
connect between MDx panel and the laptop.
If MD21 cannot read the information
from M10x, a "No Comm" message ap-
pears. This may refer to a bad connec-
tion between MD21 panel and M10x or
a possible failure in M10x main unit.
—
60 MD21 connection ports
—
61 Connection between M10x and MDx
MDx adaptor
MDx adaptor is the adaptor kit which is designed
to connect M10x main unit to an external MDx
control panel. MDx adaptor kit include a compact
IP65 socket which is to be installed on the front
panel of the each starter and a couple of
connection cables. The connection between M10x
and MDx is shown in Fig61. Details of ordering,
please refer to M10x ordering guide.
0 9. OPERATOR PANEL MDx 85
