ABB NE810 User Manual

* Refer to Safety section.
** Might require Ethernet cables to be fastened close to the unit.
Section 3 Location of interface ports and LED‘s
3BSE080633
25
Altitude Operating 2 000 m / 70 kPa
Service life Operating 10 years
Reliability
prediction
(MTBF)
MIL-HDBK- 217F Operating 630 000 hours
V
ibration
IEC 60068-2-6
(sine)
Operating
3 – 13.2 Hz: 1mm
13.2 – 100 Hz: 0.7 g
5.5 – 30 Hz: 1.5 g
30 – 50 Hz: 0.42 mm
50 – 500 Hz: 4.2 g**
Shock IEC 60068-2-27 Operating
30 g, 11 ms
100 g, 6 ms**
Bump IEC 60068-2-27 Operating 10 g, 11 ms
Packaging
Enclosure EN 60950-1 Zinc Fire enclosure
Dimension W
x H x D
With
connectors
52.5 x 100 x 101 mm
52.5 x 1
19 x 101 mm
Weight 0.7 kg
Degree of
protection
EN 60529 Enclosure IP
40
Cooling
Convection

ABB NE810 Specifications

General

Brand	ABB
Model	NE810
Category	Switch
Language	English

Summary

NOTICE

TRADEMARKS

Statement on ownership of copyrights, registered trademarks, and trademarks.

Safety Information

Warning Notices

Critical safety warnings regarding laser ports and high ambient temperatures.

Licensing Details

Information concerning the GPL license and OpenSSL Toolkit usage.

Section 1 - Industrial Ethernet 10-port Switch

Section 2 - Interface Specifications

Section 3 - Interface Ports and LED Indicators

Console Port Connection

Steps to connect to the CLI using the console port and required cable.

Power Connection Details

Information on power input terminals, voltage, and redundant connection.

I/O Connection Setup

Details for digital inputs and alarm relay outputs, including pinouts and function.

LED Indicator Status

Explanation of the status LEDs on the unit and their meanings.

Mounting Instructions

Instructions for mounting the unit on a DIN-rail.

Removal Instructions

Instructions for removing the unit from the DIN-rail.

Cooling Requirements

Spacing guidelines for convection cooling to ensure optimal performance.

Getting Started and Configuration

Initial setup steps and methods for configuring the unit via web or CLI.

Maintenance and Compliance

Maintenance Guidelines

Information regarding the maintenance requirements for the unit.

Agency Approvals and Standards

List of standards and directives the unit complies with, including EMC, Safety, and Marine.

Regulatory Notices

Specific notices related to FCC Part 15.105 and corrosive environments.

Environmental and Reliability Specifications

Type Tests and Environmental Conditions

Test levels for ESD, transients, surge, and magnetic fields according to EN standards.

Operating and Storage Environments

Specifies temperature and humidity ranges for operation, storage, and transport.

Reliability, Packaging, and Protection

Details on MTBF, vibration, shock, packaging, weight, and enclosure protection.

Documentation and System Reset

Referenced Documents

List of related ABB user manuals and configuration guides for further information.

Factory Reset Procedures

Step-by-step guide for performing a factory reset or skipping the process.
