3. Preconfigurations
The 630 series IEDs are offered with optional
factory-made application preconfigurations.
The preconfigurations contribute to faster
commissioning and less engineering of the
IED. The preconfigurations include default
functionality typically needed for a specific
application. Each preconfiguration is
adaptable using the Protection and Control
IED Manager PCM600. By adapting the
preconfiguration the IED can be configured
to suit the particular application.
The adaptation of the preconfiguration may
include adding or removing of protection,
control and other functions according to the
specific application, changing of the default
parameter settings, configuration of the
default alarms and event recorder settings
including the texts shown in the HMI,
configuration of the LEDs and function
buttons, and adaptation of the default single-
line diagram.
In addition, the adaptation of the
preconfiguration always includes
communication engineering to configure the
communication according to the functionality
of the IED. The communication engineering
is done using the communication
configuration function of PCM600.
If none of the offered preconfigurations fulfill
the needs of the intended area of application
the 630 series IEDs can also be ordered
without any preconfiguration. This option
enables full flexibility to configure the IED
from the ground up.
Table 1. REF630 preconfigurations
Description Preconfiguration
Preconfiguration A for open/closed ring feeder A
Preconfiguration B for radial overhead/mixed line feeder B
Preconfiguration C for ring/meshed feeder C
Preconfiguration D for bus sectionalizer D
Number of instances available N
Feeder Protection and Control 1MRS756380 A
REF630
Product version: 1.0 Issued: 15.09.2009
ABB 5
