Counter Function
Transmission timeout. In RS-232 handshake mode. If the CTS signal
goes inactive during transmission then the
transmission is halted. Transmission will be
resumed when CTS goes active again. The whole
frame transmission must anyhow be ready within a
specified time. If this timeout elapses then this
counter is incremented. Result will be that the end
of the frame is not being transmitted out.
Parity errors Counts parity errors detected in characters.
Overrun errors Counts overrun errors detected in characters.
Framing errors Counts framing errors detected in characters
Table 28: Link status
Parameter Function
Link status Link status in write direction: By writing 1 to the
parameter the diagnostic counters are reset to 0.
Link status in monitoring direction: If the driver is in
use by any communication protocol, the
monitoring value shows 1. In other case, the value
is 0.
8.4.2.3 Defining Ethernet port settings
Change the Ethernet port settings primarily via PCM600 to ensure that
PCM600 is able to export a consistent configuration to SYS600.
Ethernet port settings are recommended to be changed only when the
device is stand-alone and properly configured.
1. Select
Main menu/Configuration/Communication/Ethernet/Rear port.
2. Define the settings for the Ethernet port.
• IP address
• Subnet mask
• Default gateway of the optional rear port Ethernet connector
8.4.2.4 Defining serial port settings
1. Select Main menu/Configuration/Communication/COM1 or COM2.
2. Define the settings for the serial port.
It is possible to change the general serial communication parameters per port.
Select fiber or galvanic mode with the proper baud rate, parity and delays
depending on the system architecture and the selected physical communication
port.
Section 8 1MRS758754 B
Commissioning
122 REC615 and RER615
Operation Manual
