Section 4 Using the HMI
4.1 Using the local HMI
To use the LHMI, logging in and authorization are required. Password authorization
is disabled by default and can be enabled via the LHMI.
To enable password authorization, select Main menu/
Configuration/Authorization/Passwords. Set the Local override
parameter to “False”.
4.1.1 Logging in
1.
Press
to activate the login procedure.
2.
Press or to select the user level.
A070888 V2 EN
Figure 12: Selecting access level
3.
Confirm the selection with .
4. Enter the password when prompted digit by digit.
•
Activate the digit to be entered with
and .
•
Enter the character with and .
1MRS758754 B Section 4
Using the HMI
REC615 and RER615 41
Operation Manual
