Code Event Number Default value
representing of the factor
the event
E25 Output signal TS1 activated 1 0
E26 Output signal TS1 reset 2 0
E27 Output signal SS1 activated 4 0
E28 Output signal SS1 reset 8 0
E29 Output signal SS2 activated 16 0
E30 Output signal SS2 reset 32 0
E31 Output signal SS3 activated 64 0
E32 Output signal SS3 reset 128 0
E33 Output signal TS2 activated 256 256
E34 Output signal TS2 reset 512 512
Default checksum for mask V158 768
E50 Restarting * -
E51 Overflow of event register * -
E52 Temporary interruption in data communication * -
E53 No response from the module over the data communication * -
E54 The module responds again over the data communication * -
0 Not included in the event reporting
1 included in the event reporting
* No code number
- Cannot be programmed
Note!
The eventcodes E52...E54 are only generated
by the datacommunicator unit. (SACO 100M,
SRIO 1000M etc.)
Data to be
transferred
over the bus
In addition to the event data transfer the SPA-
bus allows reading of all input data (I-data) of
the module, setting values (S-data), information
recorded in the memory (V-data), and some
other data. Further, part of the data can be al-
tered by commands given over the SPA-bus. All
the data are available in channel 0.
Data Code Data flow Value range
direction
INPUTS
Filtered current measured on phase L1 I1 R 0...8.5 x I
n
Filtered current measured on phase L2 I2 R 0...8.5 x I
n
Filtered current measured on phase L3 I3 R 0...8.5 x I
n
Compensated unbalance current ∆I
c
I4 R 0...232% x ∆I
n
999 = Unbalance prot.
inhibited
Measured unbalance current ∆I I5 R 0...212% x ∆I
n
Blocking or control signal BS1 I6 R 0 = no blocking
1 = BS1-signal active
Blocking or control signal BS2 I7 R 0 = no blocking
1 = BS2-signal active
Blocking or control signal RRES I8 R 0 = no blocking
1 = RRES-signal active
