3.13. Default parameters
Before PR332/P and PR333/P are put into service, it is essential for the user to define and carefully adjust the editable parameters
to suit the installation requirements.
ABB will apply the adhesive rating plates of all the variables concerning the CB (e.g. Type of CB, Rating Plug size, etc.), thereby
allowing the user to find the information he needs when defining the parameters.
When the PR330/V module is installed, the user must adjust the installation voltage properly.
WARNING: Apart from this, it is absolutely essential for the user to change the password and carefully define
each editable parameter before putting the protection release into service.
PR332/P and PR333/P are supplied with the following predefined parameters:
Protection On/Off Thresholds Time Curve T.M. ZS Trip
L
-- 1 In 144 s I
2
t Off -- --
S
Off 6 In 50 ms K -- Off: 0,04 s --
S2 (only for PR333/P)
Off 6 In 50 ms K -- Off: 0,04 s --
D (only for PR333/P)
Off 6 In 0,2 s - 0,2 s Off: 0,13 s --
I
On 4 In -- -- -- -- --
G
Off 0,2 In 0,4 s K -- Off: 0,04 s On
U (currents)
Off 50 % 5 s Off
OT
-- Off
K LC1
Off 50 % I1
K LC2
Off 75 % I1
UV
Off 0.9 Un 5 s Off
OV
Off 1,05 Un 5 s Off
RV
Off 0,15 Un 15 s Off
RP
Off - 0,1 Pn 10 s Off
UF
Off 0,9 Fn 3 s Off
OF
Off 1,1 Fn 3 s Off
Language
-- Engl
Net Frequency
-- 50 Hz
Local Bus unit
Off
Neutral sel.
-- *
Toroid Selec.
-- None
Ext. ground tor.
Off 100 A
Rated Voltage
-- 380V
S startup
Off 6 In 100 ms
I startup
Off 4 In 100 ms
G startup
Off 1 In 100 ms
Password
-- 0001
Measuring interval
-- 60 min
Iw
Off 3 In
Power direction
-- top → bottom
Warning: harmonic distortion
Off
MCR
Off 6 In 40 ms
Start up activation threshold
0,1In
S51/P1
On Alarm-L
MM
On 2,5 In
Note:
* = OFF for three-pole versions
* = 50% for four-pole versions
* = 100% for full size versions
B1751
