ABB TPL-C Series Assembly Instructions

Assembly Instructions / TPL67-C ... TPL71-C, TPL67VC
4 Installing the turbocharger / 4.1 Completion work, if required
© Copyright 2020 ABB. All rights reserved. HZTL455311P0014_EN Rev.A July 2020
Additional function TPL..V.
These turbocharger types have adjustable guide vanes at the turbine end instead of a nozzle
ring.
u The VTG drive must be connected to the operating lever in accordance with the engineb-
uilder's instructions.
4.1 Completion work, if required
u Attach all gas, air, water and oil pipes in accordance with the enginebuilder's instructions.
u Fit insulation components.
u Fit speed sensor and plug in cable connector.
Page 17 / 21
