Operation Manual / TPL69-A10 / -A30 ... TPL77-A10 / -A30
3 Start-up / 3.1 Oil supply
© Copyright 2020 . All rights reserved. HZTL2481_EN Rev.D March 2020
3 Start-up
3.1 Oil supply
A carefully designed and installed oil supply, which functions in all pos-
sible operational conditions, is an important prerequisite for trouble-
free turbocharger operation.
The turbocharger is normally lubricated with oil from the engine oil cir-
cuit.
NOTICE
With regard to the oil supply, please observe the engine builder's spe-
cifications for lubricating oil selection, oil change intervals, oil filtration,
oil pressure and oil temperature.
Oil filtration
A lubrication oil filter system with a filter mesh size
≤
0.050 mm is ad-
equate for the turbocharger.
Page 27 / 134
