Acer AL1716 User Manual

10
ADJUSTING THE PICTURE
The descriptions for function control LEDS
Main
Menu Icon
Sub
Menu
Icon
Sub Menu
Item
Description
Contrast
Adjusts the contrast between
the foreground and background of the
screen image.
Brightness
Adjusts the background brightness of
the screen image.
Focus Adjusts picture Focus.
Clock Adjusts picture Clock.
H. Position Adjust picture Focus.
V. Position Adjust picture Clock.
N/A Warm Set the color temperature to warm white.
N/A Cool Set the color temperature to cool white.
User /Red
User/Green
User/Blue
Adjusts Red/Green/Blue intensity.

Acer AL1716 Specifications

General

Pixel pitch	0.294 x 0.294 mm
Response time	8 ms
Display diagonal	17 \
Display resolution	1280 x 1024 pixels
Vertical scan range	56.3 - 75 Hz
Horizontal scan range	31 - 81 kHz
Viewable size, vertical	270 mm
Viewing angle, vertical	130 °
Contrast ratio (typical)	500:1
Viewable size, horizontal	338 mm
Viewing angle, horizontal	140 °
Display brightness (typical)	300 cd/m²
Certification	ISO 13406-2, UL, EN60950, EN - 55022, MPR 1990, CSA, CB, TUV-GS, FCC-B, CE, TCO'99
Product color	Silver
Market positioning	-
Plug and Play	Yes
Power consumption (off)	2 W
Power consumption (typical)	44 W

Weight and Dimensions

Depth (without stand)	393 mm
Width (without stand)	377 mm
Height (without stand)	182 mm
Weight (without stand)	4600 g
