10 Chapter 1
Indicators
The computer has several easy-to-read status indicators. The front panel indicators are visible even when the
computer cover is closed.
NOTE: 1. Charging: The light shows amber when the battery is charging. 2. Fully charged: The light shows
green when in AC mode.
Icon Function Description
Power Indicates the computer's power status.
Battery Indicates the computer's battery status.
HDD Indicates when the hard disk drive is active.
Num Lock Lights up when Num Lock is activated.
Caps Lock Lights up when Caps Lock is activated.

Acer ASPIRE 5532 Specifications

General

RAM	Up to 4 GB DDR2
Graphics	ATI Radeon HD 3200
Battery	6-cell Li-ion
Weight	2.7 kg (5.95 lbs)
Storage	160 GB HDD
Display	15.6" HD (1366x768) LCD
Operating System	Windows Vista Home Premium
