Acer Aspire M5810 User Manual

47 Chapter 4
Storage Device
B: Drive Error The BIOS attempted to configure the B: drive during POST, but was unable to properly
configure the device. This may be due to a bad cable or faulty diskette drive.
Insert BOOT
diskette in A:
The BIOS attempted to boot from the A: drive, but could not find a proper boot diskette.
Reboot and
Select proper
Boot device or
Insert Boot
Media in
selected Boot
device
BIOS could not find a bootable device in the system and/or removable media drive does
not contain media.
NO ROM
BASIC
This message occurs on some systems when no bootable device can be detected.
Message
Displayed
Description
Primary
Master Hard
Disk Error
The IDE/ATAPI device configured as Primary Master could not be properly initialized by the
BIOS. This message is typically displayed when the BIOS is trying to detect and configure
IDE/ATAPI devices in POST.
Primary Slave
Hard Disk
Error
The IDE/ATAPI device configured as Primary Slave could not be properly initialized by the
BIOS. This message is typically displayed when the BIOS is trying to detect and configure
IDE/ATAPI devices in POST.
Secondary
Master Hard
Disk Error
The IDE/ATAPI device configured as Secondary Master could not be properly initialized by
the BIOS. This message is typically displayed when the BIOS is trying to detect and
configure IDE/ATAPI devices in POST.
Secondary
Slave Hard
Disk Error
The IDE/ATAPI device configured as Secondary Slave could not be properly initialized by
the BIOS. This message is typically displayed when the BIOS is trying to detect and
configure IDE/ATAPI devices in POST.
3rd Master
Hard Disk
Error
The IDE/ATAPI device configured as Master in the 3rd IDE controller could not be properly
initialized by the BIOS. This message is typically displayed when the BIOS is trying to
detect and configure IDE/ATAPI devices in POST.
3rd Slave Hard
Disk Error
The IDE/ATAPI device configured as Slave in the 3rd IDE controller could not be properly
initialized by the BIOS. This message is typically displayed when the BIOS is trying to
detect and configure IDE/ATAPI devices in POST.
4th Master
Hard Disk
Error
The IDE/ATAPI device configured as Master in the 4th IDE controller could not be properly
initialized by the BIOS. This message is typically displayed when the BIOS is trying to
detect and configure IDE/ATAPI devices in POST.
4th Slave Hard
Disk Error
The IDE/ATAPI device configured as Slave in the 4th IDE controller could not be properly
initialized by the BIOS. This message is typically displayed when the BIOS is trying to
detect and configure IDE/ATAPI devices in POST.
5th Master
Hard Disk
Error
The IDE/ATAPI device configured as Master in the 5th IDE controller could not be properly
initialized by the BIOS. This message is typically displayed when the BIOS is trying to
detect and configure IDE/ATAPI devices in POST.
Message
Displayed
Description

Acer Aspire M5810 Specifications

General

Tcase	72.7 °C
Bus type	DMI
Stepping	B1
Processor cache	8 MB
System bus rate	2.5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-700 Desktop Series
Processor socket	LGA 1156 (Socket H)
Processor threads	4
Processor codename	Lynnfield
Processing Die size	296 mm²
Processor frequency	2.66 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	1333 MHz
PCI Express slots version	2.0
Processor boost frequency	3.2 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8
Thermal Design Power (TDP)	95 W
CPU multiplier (bus/core ratio)	20
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3-SDRAM
Number of Processing Die Transistors	774 M
Memory clock speeds supported by processor	1066, 1333 MHz
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	16 GB
Internal memory	6 GB
Memory channels	Dual-channel
Maximum internal memory	8 GB
HDD interface	SATA
Optical drive type	DVD±RW
Card reader integrated	Yes
Total storage capacity	1000 GB
Compatible memory cards	miniSD, MMC, MS Duo, MS Micro (M2), MS PRO, MS PRO Duo, MS PRO-HG Duo, SD, xD
Networking features	Gigabit Ethernet
Discrete graphics card model	NVIDIA® GeForce® GT 220
Maximum graphics card memory	2.431 GB
Discrete graphics card memory	1024 GB
Audio system	High Definition Audio
Product type	PC
Bundled software	Acer eRecovery Management, Acer Arcade Deluxe, eSobi, Adobe Reader, MyWinLocker, Nero 9 Essentials, Oberon GameZone
Operating system installed	Windows 7 Home Premium
PS/2 ports quantity	2
Serial ports quantity	0
USB 2.0 ports quantity	10
Firewire (IEEE 1394) ports	1
Power supply	500 W
Chassis type	Tower
Processor ARK ID	42915
Processor package size	37.5 x 37.5 mm
Supported instruction sets	SSE4.2
Intel® Turbo Boost Technology	1.0
Physical Address Extension (PAE)	36 bit

Weight and Dimensions

Depth	443 mm
Width	180 mm
Height	373 mm
