Acer Aspire V5-132 User Manual

Your Acer notebook tour - 13
Base view
2
1
3
4
5
# Icon Item Description
1 Screw holes
Screw holes for attaching the
opt
ional second battery.
2
Ventilation and
cooling fan
Allows the computer to stay cool.
Do not cover or obstruct the
ope
nings.
3 Speakers Deliver stereo audio output.
4
Battery reset
pinhole
Insert a paperclip into the hole and
press f
or four seconds to reset the
computer (simulates removing and
reinstalling the battery).
5
Second battery
conn
ector
Connects to the second battery to
provide
power and charge the
second battery.

Acer Aspire V5-132 Specifications

General

Storage	500GB HDD
Display	11.6-inch, 1366 x 768 pixels
Graphics	Intel HD Graphics
Operating System	Windows 8
Battery	4-cell Li-ion
Wireless	802.11b/g/n
Bluetooth	Bluetooth 4.0
Dimensions	285 x 202 x 21.2 mm
Processor	Intel Celeron 1019Y
RAM	2GB / 4GB DDR3L
