Acer B277 User Manual

English
SCREEN POSITION ADJUSTMENT
In oder to optimize the best viewing position, you can adjust the height/tilt of the monitor.
• Height Adjustment
After pressing the top of the monitor then you can adjust the height of the monitor.
2
1
120mm
• Tilt
Please see the illustration below for an example of the tilt range.
Only at the highest point can 25 degrees of recline be offered for the angle of elevation.
-5°
25°

Acer B277 Specifications

General

3D	No
Screen shape	Flat
Pixel density	81.6 ppi
Display diagonal	27 \
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	55 - 75 Hz
Maximum refresh rate	75 Hz
Horizontal scan range	30 - 80 kHz
Contrast ratio (dynamic)	100000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
On/off switch	Yes
Mean time between failures (MTBF)	30000 h
RMS rated power	2 W
Number of speakers	2
Sustainability certificates	ENERGY STAR
Product color	Black
Market positioning	-
Energy efficiency scale	A to G
Power consumption (standby)	0.37 W
Power consumption (typical)	16.17 W
Tilt angle range	-5 - 25 °
Panel mounting interface	100 x 100 mm
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, DisplayPort, USB, VGA
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (without stand)	68.2 mm
Width (without stand)	614 mm
Height (without stand)	528 mm
Weight (without stand)	7140 g
