Acer B277 User Manual

English
Installation
1. Turn off your computer and unplug your computer's power cord.
2. Connect the signal cable to the VGA and /or HDMI1.4 (optional) and /or DP (optional) input socket of the monitor,
and the VGA and /or HDMI1.4 (optional) and /or DP (optional) output socket of the graphics card on the computer.
Then tighten the thumbscrews on the signal cable connector.
3. Connect the USB Cable(Optional)
Connect the USB 3.0 cable to port for fast charge.
Connect the USB 3.0 cable to port.
4. Optional: Connect the audio input socket (AUDIO IN) of the LCD monitor and the line-out port on the computer with
the audio cable.
5. Insert the monitor power cable into the power port at the back of the monitor.
6. Connect the power adapter and power cord to the monitor, then to a properly grounded AC outlet.
USB
USB
VGA
VGA
Note: Audio output is only for audio output model. Please check user manual for more instruction.

Acer B277 Specifications

General

3D	No
Screen shape	Flat
Pixel density	81.6 ppi
Display diagonal	27 \
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	55 - 75 Hz
Maximum refresh rate	75 Hz
Horizontal scan range	30 - 80 kHz
Contrast ratio (dynamic)	100000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
On/off switch	Yes
Mean time between failures (MTBF)	30000 h
RMS rated power	2 W
Number of speakers	2
Sustainability certificates	ENERGY STAR
Product color	Black
Market positioning	-
Energy efficiency scale	A to G
Power consumption (standby)	0.37 W
Power consumption (typical)	16.17 W
Tilt angle range	-5 - 25 °
Panel mounting interface	100 x 100 mm
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, DisplayPort, USB, VGA
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (without stand)	68.2 mm
Width (without stand)	614 mm
Height (without stand)	528 mm
Weight (without stand)	7140 g
