Acer B277 User Manual

English
Using the Shortcut Menu
-------------------------------------------------------------------------------------------------------------
Note: The following content is for general reference only. Actual product specications
may vary.
The OSD (onscreen display) can be used to adjust the settings of your LCD monitor. Press
the MENU key to open the OSD. You can use the OSD to adjust the picture quality, OSD
position and general settings. For advanced settings, please refer to following page:
Main page
Mode
Standard
Brightness
80
Input
HDMI
Menu
1. Hot Key1
Modes, Brightness, Volume, Gamma,
Contrast, Blue Light, Over Drive
2. Hot Key2
Modes, Brightness, Contrast, Volume,
Gamma, Blue Light, Over Drive
3. Hot Key3
Input Switch Hot Key
4. Main Menu
Hot key1 (default: Standard mode)
To choose scenario mode(sRGB,Reading,Darkroom,User, Standard, ECO, Graphics,
Movie)
sRGB
Reading
Darkroom
User
Movie
Graphics
ECO
Standard
Modes
OK
Move
Hot key2 (default: Brightness)
Open the Brightness control and select your preferred brightness setting . When you are
done, press the joystick to quit current page and store.
Brightness
80
OK
Adjust

Acer B277 Specifications

General

3D	No
Screen shape	Flat
Pixel density	81.6 ppi
Display diagonal	27 \
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	55 - 75 Hz
Maximum refresh rate	75 Hz
Horizontal scan range	30 - 80 kHz
Contrast ratio (dynamic)	100000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
On/off switch	Yes
Mean time between failures (MTBF)	30000 h
RMS rated power	2 W
Number of speakers	2
Sustainability certificates	ENERGY STAR
Product color	Black
Market positioning	-
Energy efficiency scale	A to G
Power consumption (standby)	0.37 W
Power consumption (typical)	16.17 W
Tilt angle range	-5 - 25 °
Panel mounting interface	100 x 100 mm
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, DisplayPort, USB, VGA
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (without stand)	68.2 mm
Width (without stand)	614 mm
Height (without stand)	528 mm
Weight (without stand)	7140 g
