Acer GN246HL User Manual

EN-6
Attaching / Removing the Base
SCREEN POSITION ADJUSTMENT
In oder to optimize the best viewing position, you can adjust the tilt of
the monitor by using both of your hands to hold the edges of the monitor
as shown in the figure below.
The monitor can be adjusted to 15 degrees up or 5 degrees down as indi-
cated by arrow below.
--------------------------------------------------------------------
Note: Remove the monitor and monitor base from its packaging.
Carefully place the monitor face-down on a stable surface -- use a
cloth to avoid scratching the screen.
Install:
Align the release button on the
bottom of the monitor with the
corresponding
slots on the bottom of the base.
Remove:
Depress the release button as
indicated first before removing the
base and follow the arrow direction
to remove it.

Acer GN246HL Specifications

General

3D	Yes
Panel type	TN+Film
Screen shape	Flat
Display diagonal	24 \
Display technology	LED
Native aspect ratio	16:9
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	100000000:1
Contrast ratio (typical)	-
Display number of colors	16.78 million colors
Viewing angle, horizontal	170 °
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
Feet color	Black/Red
Certification	MPR II
Product color	Black
Market positioning	Gaming
Sustainability certificates	REACH, ENERGY STAR
AC input voltage	100 - 240 V
Power consumption (off)	0.45 W
Power consumption (standby)	0.49 W
Power consumption (typical)	23 W
Package type	Box
Cables included	AC, DVI, VGA
Tilt angle range	-5 - 15 °
Panel mounting interface	100 x 100 mm

Weight and Dimensions

Depth (with stand)	178.9 mm
Height (with stand)	400.9 mm
Weight (with stand)	3520 g
Depth (without stand)	- mm
Width (without stand)	565 mm
Weight (without stand)	3071 g
