Acer V233H User Manual

14
Main Board Diagram
Flash Memory
SST25VF010A
(U402)
Panel Interface
(
CN301
)
Crystal 12MHz
(X401)
Key control Interface
(CN402)
Scalar IC TSUMU58EHL-LF-1
(Include MCU, ADC, OSD)
(U401)
D-Sub
Connector
(CN101)
H sync
V sync
RGB
DVI
Connector
(
CN102
)
D-Data
D-Clock
EEPROM
M24C04
(U402)
