Main Board Layout
Symbol Description Symbol Description
U401 IC TSUMU58EHL-LF-1 CN402 WAFER
U701 IC AP1117E33L-13 CN701 WAFER 9P RIGHT ANELE PITCH
U106 IC AZC099-04S SOT23-6L CN301 CONNECTOR
U107 IC AZC099-04S SOT23-6L X401 14.31818MHZ/32PF/49US0
U403 M24C04-WMN6TP SO8 CN101
D-SUB 15PIN VERTICAL CONN WITH
SCREW
U402 SST25VF010A-33-4C-SAE CN102 DVI 24PIN CONN F
