11
Saving and Recalling
Navigating the menu can be quite difficult on the Agilent 33120A. If you have a certain setup you use
over and over, it is a good idea to store the settings. You can then recall your settings with two button
presses. You can store up to three different setups.
1. Set the signal generator up with the exact signal you want.
2. Press Shift -> Store and select 1,2 or 3 then press the Enter button.
3. To recall the setup, press Recall then use the wheel to choose 1,2 or 3. Press the Enter button.
4. Note: The 50 ohm / High Z information is also stored into memory as well.
More Information
This UTA Quick Guide is intended to familiarize students quickly with the undergraduate lab equipment.
For more information on the Agilent 33120A signal generator please contact
EE_UG_LABS@uta.edu to
schedule addition training.
To Previous Page
