Agilent Technologies N9310A Quick Start Guide

N9310A RF Signal generator
Quick Start Guide 23
Factory Default Settings
Item Default Item Default
Frequency 3.000 000 0000 GHz Sweep Scaling Linear
Amplitude –127.0 dBm Sweep/Point Trigger Immediate
LF Out Off Sweep Direction Up
LF Out Freq 1.0000 kHz Trig In Polarity Negative
LF Out Ampl 500 mV Modulation
Mod On/Off On Modulation State Off
RF On/Off Off AM Depth 0.0 %
Sweep FM Deviation 0.000 rad
Sweep Mode Off FM Deviation 20 Hz
RF Start 9.0000 kHz Pulse Period 200 ms
RF Stop 3.000 000 0000 GHz Pulse Width 100 ms
Ampl Start –127.0 dBm Modulation Source INT
Ampl Stop –126.0 dBm Modulation Rate 1.0000 kHz
LF Start 20.0 Hz Ext Coupling AC
LF Stop 80.0000 kHz System
#Point 10 Catalog Local
Step Dwell 10.0 ms F Noise Mode Normal
Sweep Repeat Cont Reference Source Int_10MHz
