20.Connect the Alien head LED-cable to the system board.
21. Adhere the display cable to the system board.
22.Connect the display cable to the system board and close the latch to secure the cable.
23.Adhere the tape that secures the display-cable connector latch to the system board.
24.Place the Type-C bracket on the system board and align the screw holes on the bracket to the screw holes on the system board.
25.Replace the two screws (M2x4) that secure the Type-C bracket to the system board.
Next steps
1. Install the
battery.
2. Install the
rear-I/O cover.
3. Install the wireless card.
4. Install the 2230 solid-state drive or 2280 solid-state drive in slot one, whichever applicable.
5. Install the 2230 solid-state drive or 2280 SSD in slot two, whichever applicable.
6. Install the
base cover.
7. Follow the procedure in After working inside your computer.
Fan and heat-sink assembly
Removing the fan and heat-sink assembly
Prerequisites
1. Follow the procedure in
Before working inside your computer.
2. Remove the base cover.
3. Remove the
2230 solid-state drive or 2280 solid-state drive in slot one, whichever applicable.
4. Remove the 2230 solid state drive or 2280 solid-state drive in slot two, whichever applicable.
5. Remove the wireless card.
6. Remove the rear-I/O cover.
7. Remove the
battery.
8. Follow the procedure from step 1 to step 21 in removing the system board (NVIDIA GeForce 3060/3070 Ti/3080 Ti) or system
board (NVIDIA GeForce 3050 Ti), whichever applicable.
NOTE: The system board can be removed and installed along with the memory, ethernet and audio board, USB board, and
fan and heat sink-assembly. This simplifies the removal and installation procedure and avoids breaking the thermal bond
between the system board and heat sink.
About this task
CAUTION: The heat sink may become hot during normal operation. Allow sufficient time for the heat sink to cool before
you touch it.
NOTE: For maximum cooling of the processor, do not touch the heat transfer areas on the heat sink. The oils in your skin can
reduce the heat transfer capability of the thermal grease.
The following image(s) indicate the location of the fan and heat-sink assembly and provides a visual representation of the removal
procedure.
59
