Alienware m15 R7 User Manual

System setup
CAUTION: Unless you are an expert computer user, do not change the settings in the BIOS Setup program. Certain
changes can make your computer work incorrectly.
NOTE: Before you change BIOS Setup program, it is recommended that you write down the BIOS Setup program screen
information for future reference.
Use the BIOS Setup program for the following purposes:
● Get information about the hardware installed in your computer, such as the amount of RAM and the size of the hard drive.
● Change the system configuration information.
● Set or change a user-selectable option, such as the user password, type of hard drive installed, and enabling or disabling base
devices.
BIOS overview
The BIOS manages data flow between the computer's operating system and attached devices such as hard disk, video adapter,
keyboard, mouse, and printer.
Entering BIOS setup program
Steps
1. Turn on (or restart) your computer.
2. During POST, when the DELL logo is displayed, watch for the F2 prompt to appear, and then press F2 immediately.
NOTE: The F2 prompt indicates that the keyboard is initialized. This prompt can appear very quickly, so you must watch for
it, and then press F2. If you press F2 before the F2 prompt, this keystroke is lost. If you wait too long and the operating
system logo appears, continue to wait until you see the desktop. Then, turn off your computer and try again.
Navigation keys
NOTE: For most of the System Setup options, changes that you make are recorded but do not take effect until you restart the
system.
Keys Navigation
Up arrow Moves to the previous field.
Down arrow Moves to the next field.
Enter Selects a value in the selected field (if applicable) or follow the link in the field.
Spacebar Expands or collapses a drop-down list, if applicable.
Tab Moves to the next focus area.
Esc Moves to the previous page until you view the main screen. Pressing Esc in the main screen displays a message
that prompts you to save any unsaved changes and restarts the system.
Boot Sequence
Boot Sequence allows you to bypass the System Setup–defined boot device order and boot directly to a specific device (for
example: optical drive or hard drive). During the Power-on Self Test (POST), when the Dell logo appears, you can:
● Access System Setup by pressing F2 key
● Bring up the one-time boot menu by pressing F12 key
71

Alienware m15 R7 Specifications

General

Processor cache	24 MB
Processor cores	14
Processor model	i7-12700H
Processor family	Intel® Core™ i7
Processor frequency	- GHz
Configurable TDP-down	35 W
Processor manufacturer	Intel
On-board graphics card	Yes
Discrete graphics card model	NVIDIA GeForce RTX 3070 Ti
On-board graphics card model	Intel Iris Xe Graphics
Discrete graphics card memory	8 GB
Discrete graphics memory type	GDDR6
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	NVMe, PCI Express
Storage media	SSD
SSD form factor	M.2
Optical drive type	No
Total storage capacity	1000 GB
Number of SSDs installed	1
Trial software	Microsoft Office 30 Day
Operating system installed	Windows 11 Home
Operating system architecture	64-bit
Memory slots	2x SO-DIMM
Internal memory	32 GB
Memory clock speed	4800 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR5-SDRAM
Color name	Dark Side of the Moon
Form factor	Clamshell
Product type	Laptop
Product color	Gray
Market positioning	Gaming
Panel type	WVA
Color gamut	99 %
Pixel density	188.3 ppi
RGB color space	DCI-P3
Display diagonal	15.6 \
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display brightness	400 cd/m²
Native aspect ratio	16:9
Maximum refresh rate	240 Hz
Contrast ratio (typical)	1000:1
Audio chip	Realtek ALC3254
Speaker power	2 W
Number of built-in speakers	2
Front camera HD type	HD
Video capturing speed	30 fps
Front camera resolution	1280 x 720 pixels
Front camera resolution (numeric)	0.92 MP
Antenna type	2x2
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version	5.2
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN controller model	Killer Wi-Fi 6E 1675i
Ethernet LAN data rates	10, 100, 1000, 2500 Mbit/s
WLAN controller manufacturer	Killer
Charging port type	DC-in jack
USB 2.0 ports quantity	0
Power adapter barrel connector	7.4 mm
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Pointing device	Touchpad
Keyboard language	German
Keyboard backlit color	RGB
Keyboard number of keys	86
Battery weight	340 g
Battery voltage	13.35 V
Battery capacity	86 Wh
Battery recharge time	3 h
Number of battery cells	6
AC adapter power	240 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	3.5 A
AC adapter output voltage	19.5 V
Operating shock	110 G
Operating altitude	-15.2 - 3048 m
Non-operating shock	160 G
Operating vibration	0.66 G
Non-operating altitude	-15.2 - 10668 m
Non-operating vibration	1.3 G
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	AC
Other materials content per package	218 g
Polystyrene (PS) content per package	0 g
Corrugated cardboard content per package	1102 g
Corrugated cardboard content per box for accessories	101 g
Polyethylene terephthalate (PET) content per package	15 g
Corrugated cardboard content per shipping (inner) case	128 g
Corrugated cardboard content per sleeve for accessories	873 g
Pallet width	1000 mm
Pallet length	1200 mm
Pallet weight	413000 g
Quantity per pallet	81 pc(s)
Pallet volume weight	73600 g
Quantity per pallet layer	27 pc(s)
Number of layers per pallet	3 pc(s)
Maximum number of stacking cartons	6 pc(s)
Quantity per intermodal container (20ft)	1620 pc(s)
Quantity per intermodal container (40ft)	3402 pc(s)
Package depth	553 mm
Package width	345.5 mm
Package height	76 mm
Package weight	5000 g
Package material	Corrugated cardboard, Polyethylene terephthalate (PET)
EPEAT rating	82.55 %

Weight and Dimensions

Depth	272.5 mm
Width	356.2 mm
Weight	2690 g
Height (rear)	20.6 mm
Height (front)	12.9 mm
