CAUTION: To avoid damaging your computer, ensure that the Tron-light cable is not pinched when sliding the rear

I/O-cover into palm-rest and keyboard assembly.

Steps

1. With the correct orientation, slide the rear I/O-cover into the palm-rest and keyboard assembly, and snap it into place.

2. Slide the left and right Tron-light cables into their respective connectors on the system board and close the latches to secure the

cables.

3. Replace the two screws (M2.5x9) that secure the rear I/O-cover to the palm-rest and keyboard assembly.

Next steps

1. Install the

base cover.

2. Follow the procedure in After working inside your computer.

Power-adapter port

Removing the power-adapter port

Prerequisites

1. Follow the procedure in

Before working inside your computer.

2. Remove the base cover.

3. Remove the rear I/O-cover.
