ALLEN & HEATH GLD User Manual

GLD User Guide 33 AP8561 iss.3
MixProcessing
20MixChan nels Configureasmono/stereoGroups ,Aux,Main,Matrix
Mai ns=None,LR,LCR.LR+M(bus),LR+M(s um)
ExternalInput As s i gna bl esource
Trim +/‐24dBdigita ltri m
Polarity Normal /Revers e
Insert As si gntoanysockets,In/Out,+4dBu/‐10dBVlevel
Delay Upto170ms ,Bypassswitch
Mixglobal setting‐ms,feet,mete rs ,samples
GEQ
Type Consta nt1/3octave,28ba nds31Hz‐16kHz
Gai n +/‐12dB
GEQFaderFlipMode 2overlappingfr equencyba n ksonstripfaders
SELkeyresetsfr equenc ybandto0dB
RTAfollowingPAFLisdisplayedonstripme ters
PEQ
Type 4‐Bandfullyparametr ic,+/‐15dB
FrequencyRange Globa lsetti ngforMi xes=20‐20kHzor'Ana logue'
Ana l ogueRanges 20‐2 00Hz,35‐1kHz,500‐15kHz,2k‐20kHz
Band
1 Sel ectabl eLFShelving,Bell,Hi‐Pass
Band2Bell
Band3Bell
Band4 Sel ectabl eHFShelvi ng,Bell,Lo‐Pa s s
BellWi dth Non‐constantQ,variable,1.5to1/9thoc tave
Shelvi ngType Cl ass icBaxandal l
Hi‐Pas s ,Lo‐PassFilter 12dB/octave
Compressor
Sidechain Selfkey,In/Out,Sel'l is ten'
SidechainLo‐CutFilter 12dB/octa ve,Freq20Hz–5kHz
SidechainHi ‐CutFilter 1 2dB/oc tave,Freq120Hz–20kHz
Thres hol d ‐46dButo18dBu
Ratio 1:1toinfinity
Attack 300us –300ms
Release 100ms–2s
Knee Soft/Hard
ManualTypes PeakManual,RMSManual
AutoTypes VocalAuto,OptoAuto,Punc hBag
filterin/outwithsel ‘listen’
MainsPower
GLD‐80 100‐240VAC,50/60Hz,95Wmax
GLD‐112 100‐240VAC,5 0/60Hz,110Wmax
GLD‐AR2412 100 ‐240VAC,50/60Hz,70Wmax
GLD‐AR84 100‐240VAC,50/60Hz,20Wmax
Dimensionsand Weights
GLD‐80Mixer Wi dthxDepthxHeight
Unpacked 730x577x159mm(28.7"x22.7"x6.2")
Packedins hippingbox 930x730x2 90mm(36.6"x28.6"x11.4")
Unpackedwei ght 16.5kg(36l bs )
Packedweight 21.2kg(46.6lbs)
GLD‐112Mixer WidthxDepthxHeight
Unpacked 1000x 577x159mm(39.4"x22.7"x
6.2")
GLD‐AR2412AudioRack Wi dthxDepthxHeight
Unpacked 483x220x137mm(19"x8.6"x5.4")3Urack
Packedins hippingbox 600x350x2 50mm(23.6"x13.7"x9.8"
Unpackedwei ght 5kg(1 1lbs )
Packedweight 6.4kg(14lbs)
GLD‐AR2412AudioRack Wi dthxDepthxHeight
Unpacked 483x220x48mm(19"x8.6"x1.9")1Urack
Packedins hippingbox 600x330x1 43mm(23.6"x12.9"x5.6")
Unpackedwei ght 3kg(6 .6lbs)
Packedweight 4.4kg(9.7lbs)
GLD-80 = 730
GLD-112 = 1000
Talkback As s i gna bl esource
Mode Latched/Momentary,PAFLDimoption
HighPassFi lter 12dB/octave,20Hz‐2kHz
Routing ToGroups,Aux,Mai n,Matrix
Level Trim + /‐24dB
SignalGenera tor Sine,WhiteNoise,PinkNoi s e,Ba ndpassNoi s e
Sine,Bandpasssweep 20‐20kHz
Controls Level,Mute
Routing ToGroups,Aux,Mai n,Matrix
RTA 31‐Bands1/3octave20‐20kHz
Source FollowsselectedPAFLsource
Pea kBandIndi cation Opti ontodispl aydominantfrequency
