MIDI Protocol – ISSUE 1
In the following tables, the source is shown on the left and the destination is
shown at the top.
Each parameter number includes one MSB (MB) and one LSB (LB).
Mute Parameter Numbers – Inputs to LR/Aux (MB/LB)
MSB LSB
MSB LSB MSB LSB MSB LSB LR 00 44
Ip1 00 00 Ip25 00 18 Grp1 00 30 Aux1 00 45
Ip2 00 01 Ip26 00 19 Grp2 00 31 Aux2 00 46 MSB LSB
Ip3 00 02 Ip27 00 1A Grp3 00 32 Aux3 00 47 DCA1 02 00
Ip4 00 03 Ip28 00 1B Grp4 00 33 Aux4 00 48 DCA2 02 01
Ip5 00 04 Ip29 00 1C Grp5 00 34 Aux5 00 49 DCA3 02 02
Ip6 00 05 Ip30 00 1D Grp6 00 35 Aux6 00 4A DCA4 02 03
Ip7 00 06 Ip31 00 1E Grp7 00 36 Aux7 00 4B DCA5 02 04
Ip8 00 07 Ip32 00 1F Grp8 00 37 Aux8 00 4C DCA6 02 05
Ip9 00 08 Ip33 00 20 Grp9 00 38 Aux9 00 4D DCA7 02 06
Ip10 00 09 Ip34 00 21 Grp10 00 39 Aux10 00 4E DCA8 02 07
Ip11 00 0A Ip35 00 22 Grp11 00 3A Aux11 00 4F
Ip12 00 0B Ip36 00 23 Grp12 00 3B Aux12 00 50
Ip13 00 0C Ip37 00 24 MSB LSB
Ip14 00 0D Ip38 00 25 MGRP1 04 00
Ip15 00 0E Ip39 00 26 MSB LSB MGRP2 04 01
Ip16 00 0F Ip40 00 27 MSB LSB FX1Snd 00 51 MGRP3 04 02
Ip17 00 10 Ip41 00 28 FX1Rtn 00 3C FX2Snd 00 52 MGRP4 04 03
Ip18 00 11 Ip42 00 29 FX2Rtn 00 3D FX3Snd 00 53 MGRP5 04 04
Ip19 00 12 Ip43 00 2A FX3Rtn 00 3E FX4Snd 00 54 MGRP6 04 05
Ip20 00 13 Ip44 00 2B FX4Rtn 00 3F MGRP7 04 06
Ip21 00 14 Ip45 00 2C FX5Rtn 00 40 MGRP8 04 07
Ip22 00 15 Ip46 00 2D FX6Rtn 00 41 MSB LSB
Ip23 00 16 Ip47 00 2E FX7Rtn 00 42 Mtx1 00 55
Ip24 00 17 Ip48 00 2F FX8Rtn 00 43 Mtx1 00 56
Mtx1 00 57
MUTE
MUTE
MUTE
MUTE
MUTE
MUTE
MUTE
MUTE
MUTE
