4 XONE:02 User Guide
Contents
Important Safety Instructions.......................3
Introduction and Quick Start........................4
Connectors and Panel Controls ..................6
Installation and Cable Diagrams................10
Operating Instructions ...............................12
Replacing the Faders.................................15
Repositioning the Transform Switches......15
Using Effects .............................................16
Linking Consoles....................................... 17
Recording.................................................. 17
Specification.............................................. 18
Glossary .................................................... 20
Order Codes..............................................22
Tips and Troubleshooting......................... 23
Introduction
Welcome to the XONE:02 professional DJ mixer. This stylish and solidly built dual channel
performance mixer presents a unique combination of creative tools for the professional turntablist or
battle DJ. Above all, it features a sound quality second to none. XONE:02 has been designed and
constructed using the same rigorous standards we apply to our large format professional consoles used
and respected by top engineers and performers throughout the world. We have had great fun designing
this new range. We are sure you will get even more enjoyment using it.
We know you want to get started right away. For this reason we have kept this user guide concise and
to the point. We recommend you read it through first. However, if even that is too much then at least
read the QUICK START page before you plug up and go. This user guide refers to the XONE:02. For
further information on the basic principles of audio system engineering and mixing technique please
refer to one of the specialist publications available from bookshops and audio equipment dealers.
We are able to offer further product support through our world-wide network of approved dealers and
service agents. You can also access our Web site on the Internet for information on our product range,
assistance with your technical queries or simply to chat about matters audio. To help us provide the
most efficient service please keep a record of your console serial number, and date and place of
purchase to be quoted in any communication regarding this product.
Check out our home site www.allen-heath.com for information on the company and its pedigree,
our full product range and our design philosophy. We also have a site dedicated to the exciting XONE
console range www.xone.co.uk.
Key Features
• Dual stereo channels with mixable A and B inputs featuring independent level control and channel
reverse
• A inputs switchable for line and RIAA phono sources
• 2 microphone inputs with vocal EQ, effect in/out and independent level control
• Balanced XLR main mix output with VCA master level control
• Booth output for local stereo monitoring
• EFFECT loop with silent FET switching to add external effects
• Link in and out connections for daisy chaining mixers, recording or booth output
• 3 Band +6/-26 asymmetric EQ with extended cut
• VCA PAN controls to adjust LR balance or for performance effect
• Ultra smooth gold contact dual rail conductive plastic VCA crossfader and channel faders
• All faders are VCA for noise free operation and have reverse and variable contour controls
• Rotatable TRANSFORM switches for stutter effects
• Removable face plate for fader servicing and user preferred transform switch positioning
• Advanced headphones cue system with cue/mix select, cue crossfader and large meters
• Sensible performance control layout makes it very easy to use
• Universal internal power supply for any worldwide mains voltage
