CABLES AND CONNECTIONS
USB TYPE A USB TYPE B
MAX 2M
SPDIF RCA - 75 ohm coax
MIDI - 5-pin DIN
SPDIF OPTICAL - TOSLINK
1= ground
2= hot (+ )
3= cold (-)
BALANCED
XLR FEMALE
RCA phono jacks
XLR MALE
2= hot (+ )
1= ground
3= cold (-)
CABLE D
CABLE E
CABLE A
CABLE G
Sleeve= ground
Ring= cold (-)
Tip= hot (+ )
BALANCED
1= ground
2= hot (+ )
3= cold (-)
UNBALANCED
2= hot (+ )
1= ground
3= cold (-)
CABLE
F
Sleeve= ground
Ring= cold (-)
Tip= hot (+ )
BALANCED
CABLE H
BALANCED
BALANCED
XLR FEMALE
UNBALANCED
XLR FEMALE
XLR MALE
BALANCED
XLR MALE
UNBALANCED
UNBALANCED
CABLE
B
UNBALANCED
CABLE C
Sleeve= ground
Ring= cold (-)
Tip= hot (+ )
BALANCED
Sleeve= ground
Ring= cold (-)
Tip= hot (+ )
BALANCED
UNBALANCED
adapter
UNBALANCED
CABLE I
CABLE
J
CABLE K
CABLE L
