14 Rockwell Automation Publication 5069-IN013D-EN-P - April 2018
CompactLogix 5380 Controllers
Specifications
This table lists a subset of controller specifications. For a complete list of specifications, see the CompactLogix 5380 and Compact GuardLogix5380
Controllers Technical Data, publication
5069-TD002.
Attribute
5069-L306ER, 5069-L306ERM, 5069-L310ER, 5069-L310ER-NSE, 5069-L310ERM, 5069-L320ER, 5069-L320ERM,
5069-L330ER, 5069-L330ERM, 5069-L340ER, 5069-L340ERM, 5069-L350ERM, 5069-L380ERM, 5069-L3100ERM
Temperature, operating
IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Na, Operating Thermal Shock)
0 °C < Ta < +60 °C
(+32 °F < Ta < +140 °F)
Temperature, surrounding air, max 60 °C (140 °F)
Enclosure Type rating None (open-style)
Voltage ratings
MOD Power voltage range 18…32V DC
MOD Power current, max 450 mA
MOD Power inrush 850 mA for 125 ms
MOD Power Passthrough
(1)
9.55 A @ 18…32V DC
MOD Power current rating, max
10 A
Do not exceed 10 A current draw at the MOD power RTB.
SA Power voltage ranges
(2)
0…32V DC
0…240V AC, 47…63 Hz
ATEX/IECEX, 125V AC max
SA Power current, max
(2)
10 mA (DC power)
25 mA (AC power)
SA Power Passthrough
(2)
,
(3)
9.95 A @ 0…32V DC
9.975 A @ 0…240V AC, 47…63 Hz
ATEX/IECEX, 125V AC max
SA Power current rating, max
(2)
10 A
Do not exceed 10 A current draw at the SA power RTB.
Isolation voltage
300V (continuous), Basic Insulation Type, SA, and MOD Power to Backplane
300V (continuous), Basic Insulation Type, SA to MOD Power
300V (continuous), Basic Insulation Type, Ethernet to Backplane
300V (continuous), Double Insulation Type, Ethernet to MOD Power
300V (continuous), Double Insulation Type, Ethernet to SA Power
50V (continuous), Functional Insulation Type, Ethernet to USB
300V (continuous), Basic Insulation Type, USB to Backplane
300V (continuous), Double Insulation Type, USB to MOD Power
300V (continuous), Double Insulation Type, USB to SA Power
No isolation between Ethernet ports
Type tested at 1500V AC for 60 s
Wire size
5069-RTB4-SCREW, 5069-RTB6-SCREW connections:
0.5...1.5 mm
2
(22…16 AWG) solid or stranded copper wire that is rated at 105 °C (221 °F), or greater, 3.5 mm (0.14 in.) max
diameter including insulation, single wire connection only
5069-RTB4-SPRING, 5069-RTB6-SPRING connections:
0.5...1.5 mm
2
(22…16 AWG) solid or stranded copper wire that is rated at 105 °C (221 °F), or greater, 2.9 mm (0.11 in.) max
diameter including insulation, single wire connection only
Ethernet connections:
Ethernet Cabling and Installation according to IEC 61918 and IEC 61784-5-2
Insulation stripping length
5069-RTB4-SCREW, 5069-RTB6-SCREW connections: 12 mm (0.47 in.)
5069-RTB4-SPRING, 5069-RTB6-SPRING connections: 10 mm (0.39 in.)
Terminal block torque
5069-RTB4-SCREW & 5069-RTB6-SCREW: 0.4 N•m (3.5 lb•in)
5069-RTB4-SPRING & 5069-RTB6-SPRING: N/A
North American temperature code T4
ATEX temperature code T4
IECEx temperature code T4
(1) Maximum level of MOD Power current that the controller can pass through to the next module in the system. The specific level of current passed through varies based on system configuration.
(2) SA power specifications are based on the number and type of Compact 5000™ I/O modules used in the system. If the set of I/O modules that are used in the system require AC and DC voltage, you must install a 5069-FPD field
potential distributor to separate the module types.
(3) Maximum level of SA Power current that the controller can pass through to the next module in the system. The specific level of current passed through varies based on system configuration.
