24 PanelView Component HMI Terminals
Publication 2711C-IN001H-EN-P - July 2014
The input power terminal block supports these wire sizes.
Follow these steps to connect power.
1. Verify that the terminal is not connected to a power source.
2. Secure the 24V DC power wires to the terminal block.
3. Secure the functional earth ground wire to the functional earth ground terminal screw on the
terminal block.
WARNING: Use supply wires suitable for 30 °C (86 °F) above surrounding ambient.
WARNING: If you connect or disconnect wiring while the power is on, an electrical arc can
occur. This could cause an explosion in hazardous location installations. Be sure that power is
removed or the area is nonhazardous before proceeding.
Wire Specifications for Input Power Terminal Block
Wire Type Dual-wire Gauge
(1)
(1)
Two-wire maximum per terminal.
Single-wire
Gauge
Terminal Screw
Torque
Stranded or solid Cu 90 °C (194 °F) 0.33…1.31 mm
2
(22…16 AWG)
0.33…2.08 mm
2
(22…14 AWG)
0.45…0.56 Nm
(4…5 lb-in.)
ATTENTION: Disconnect all power before installing or replacing components. Failure to
disconnect power may result in electrical shock or damage to the terminal.
ATTENTION: Do not wire more than 2 conductors on any single terminal.
