26 PanelView Component HMI Terminals
Publication 2711C-IN001H-EN-P - July 2014
RS-422/RS-485 Port
The RS-422/RS-485 port is a nonisolated port that supports point-to-point communications using
Full-Duplex or Half-Duplex mode
• In Full-Duplex mode, both devices can transmit and receive simultaneously.
The transmit and receive pair are wired individually.
• In Half-Duplex mode, only one device can transmit at a time while the other device receives. A
single differential, twisted pair connects to both receive and transmit pairs (R and T and on one
wire, R- and T- on the other).
The RS422/485 port has integrated 121 ohm termination between the R and R- signal pair. This value is
compatible with RS422 and RS485 electrical specifications. Additional termination on the PanelView
Component end of communication cables is not required.
Troubleshooting
If your terminal does not start up correctly, check for adequate power and indicator states during powerup.
Check for Adequate Power
A terminal that does not receive adequate power could cause unpredictable behavior.
Verify the power requirements in the Specifications table.
1747-CP3 Serial 9-pin D-shell to 9-pin D-shell null modem cable C200, C300, C400, C600, C1000
1761-CBL-PM02 Serial 9-pin D-shell to 8-pin mini DIN cable,
2 m (6.56 ft)
C200, C300, C400, C600, C1000
2711C-CBL-AB03 RS-485 5-pin to RJ45 cable C200, C300, C600, C1000
RS-422/RS-485 Connector Pinout
Pin Signal
1T
2T–
3R
4R–
5 S (Shield)
Cables for PanelView Component Terminals
Cat. No. Description For Use With
