Wiring and Grounding Guidelines for PanelView Plus Terminals 15
Connect PanelView Plus
DC Terminals to DC Power
PanelView Plus terminals with a 24V DC power input have these power ratings.
The power supply is internally protected against reverse polarity of the DC+ and
DC- connections. Connecting DC+ or DC- to the earth terminal may damage
the device.
Follow these steps to connect a PanelView Plus device to a DC power source.
1. Verify that the device is not connected to a power source.
2. Secure the DC power wires to the terminal block.
Make sure you connect the DC+ and DC- wires to the correct positions
on the power terminal block.
3. Secure the earth/ground wire.
• On the 400 and 600 terminals, secure the earth/ground wire to the
functional earth/ground terminal on the input power terminal block.
• On the 700 to 1500 terminals, secure the earth/ground wire to the
earth/ground terminal screw at the bottom of the display.
Table 7 - DC Power Ratings
Terminal Input Range
PanelView Plus 400 and 600
PanelView Plus Compact 400, 600
24V DC nom (18…30V DC)
25 W max (1.0 A at 24V DC)
PanelView Plus 6 (700 to 1500)
PanelView Plus 700 to 1500
PanelView Plus Compact 1000
24V DC nom (18…32V DC)
70 W max (2.9 A at 24V DC)
Table 8 - Wire Specifications for DC Power Terminal Block
Terminal Wire Type
Dual-wire
Gauge
(2)
Single-wire
Gauge
Terminal Screw Torque
PanelView Plus 400, 600
PanelView Plus Compact 400, 600
Copper
Stranded
or solid
Cu 90 °C (194 °F)
0.3…1.3 mm
2
22…16 AWG
0.3…2.1 mm
2
22…14 AWG
0.45…0.56 N•m
(4…5 lb•in)
700 to 1500 logic module
series A…D
(1)
0.23…0.34 N•m
(2…3 lb•in)
700 to 1500 logic module
series E and later
(1)
Copper
Stranded
or solid
Cu 90 °C (194 °F)
0.3…1.3 mm
2
22…16 AWG
0.3…2.1 mm
2
22…14 AWG
0.56 N•m (5 lb•in)PanelView Plus Compact 1000
PanelView Plus 6 terminals
series A or later
(1) Terminals with these logic modules support FactoryTalk View ME software, version 5.1 or earlier.
(2) Two-wire maximum per terminal.
WARNING: Explosion Hazard
Do not disconnect equipment unless power has been switched off and the
area is known to be nonhazardous.
Disconnect all power before installing or replacing components. Failure to
disconnect power may result in electrical shock or damage to the device.
