Rockwell Automation Publication 2711P-TD001D-EN-P - February 2011
Wiring and Grounding Guidelines for PanelView Plus Terminals 21
Communication Port
Isolation
PanelView Plus terminals contain integral and modular (externally attached)
communication ports. Some of these ports contain electrical isolation depending
on the catalog number of the terminal or communication module.
Table 14 - Integral Communication Port Isolation
Communication Port 400 and 600 Terminals 700 to 1500 Terminals
(1)
(1) Includes PanelView Plus 6 terminals and PanelView Plus terminals supporting FactoryTalk View ME software,
version 5.1 or earlier.
RS-232 Nonisolated Isolated
USB Nonisolated Nonisolated
Ethernet Isolated Isolated
Table 15 - 400 and 600 Modular Communication Port Isolation
Communication Port Module Isolation
RS-232 2711P-RN22C Isolated
DH-485 2711P-RN3 Nonisolated
DH+ 2711P-RN8 Isolated
Remote I/O 2711P-RN1 Isolated
DeviceNet 2711P-RN10C Isolated
ControlNet 2711P-RN15C Isolated
(1)
(1) NAP port is nonisolated.
Table 16 - 700 to 1500 Modular Communication Port Isolation
Communication Port Module Isolation
DH-485 2711P-RN6, 2711P-RN6K Isolated
DH+ 2711P-RN6, 2711P-RN6K Isolated
Remote I/O
(1)
(1) Remote I/O and DeviceNet networks are supported but no longer available for order.
2711P-RN6 Isolated
DeviceNet
(1)
2711P-RN10H Isolated
ControlNet 2711P-RN15S, 2711P-RN15SK Isolated
