Rockwell Automation Publication 2711P-TD001D-EN-P - February 2011

Wiring and Grounding Guidelines for PanelView Plus Terminals 17

PanelView Plus AC

Terminals

PanelView Plus terminals that operate on AC power require the following:

• Protective earth/ground connection on the 400 and 600 terminals

• Protective earth/ground and a functional earth/ground connection on the

700 to 1500 terminals

PanelView Plus 400 and 600 AC Terminals

All PanelView Plus 400 and 600 terminals operate on AC power.

PanelView Plus 700 to 1500 AC Logic Modules

All PanelView Plus 6 and PanelView Plus 700 to 1500 terminals that operate on

AC power use an AC logic module.

Table 9 - PanelView Plus Terminals with AC Power Supplies

Cat. No. Terminal Type

• 2711P-K4M5A, 2711P-K4M20A

• 2711P-K4C5A, 2711P-B4C5A

• 2711P-K4C20A, 2711P-B4C20A

PanelView Plus 400

• 2711P-K6M5A, 2711P-T6M5A, 2711P-B6M5A

• 2711P-K6M20A, 2711P-B6M20A

• 2711P-K6C5A, 2711P-T6C5A, 2711P-B6C5A

• 2711P-K6C20A, 2711P-T6C20A, 2711P-B6C20A

PanelView Plus 600

Table 10 - AC Logic Modules

Cat. No. Logic Modules with AC Power Input

PanelView Plus 6 (700 to 1500) Terminals

2711P-RP8A Logic module with 512 MB nonvolatile memory and RAM

2711P-RP9A Logic module with 512 MB nonvolatile memory and RAM

PanelView Plus 700 to 1500 Terminals

(1)

(1) These logic modules support FactoryTalk View ME software, version 5.1 or earlier.

2711P-RPA Logic module without nonvolatile memory and RAM

2711P-RP1A Marine-certified logic module with 64 MB nonvolatile memory and RAM

2711P-RP2A Marine-certified logic module with 128 MB nonvolatile memory and RAM

2711P-RP6A Marine-certified CE Logic module with 128 MB nonvolatile memory and RAM

2711P-RP3A Marine-certified logic module with 256 MB nonvolatile memory and RAM

2711P-RP7A Marine-certified CE logic module with 256 MB nonvolatile memory and RAM
