Wiring and Grounding Guidelines for PanelView Plus Terminals 7
PanelView Plus
Nonisolated DC Terminals
PanelView Plus terminals with a nonisolated DC power input
require both of these:
• Separate, external power supply for each device
• Functional earth/ground connection
Nonisolated DC Terminals
All PanelView Plus 400 and 600 terminals, and PanelView Plus Compact
terminals that operate on DC power contain nonisolated, DC power supplies.
Nonisolated DC Logic Modules
Nonisolated, DC logic modules are used with PanelView Plus 700 to 1500
terminals supporting FactoryTalk View ME software, version 5.1 or earlier.
Table 2 - Terminals with Nonisolated DC Power Supplies
Cat. No. Terminal Type
• 2711P-K4M5D, 2711P-K4M20D
• 2711P-K4C5D, 2711P-B4C5D
• 2711P-K4C20D, 2711P-B4C20D
PanelView Plus 400
• 2711P-K6M5D, 2711P-T6M5D, 2711P-B6M5D
• 2711P-K6C5D, 2711P-T6C5D, 2711P-B6C5D
• 2711P-K6M20D, 2711P-T6M20D, 2711P-B6M20D
• 2711P-K6C20D, 2711P-T6C20D, 2711P-B6C20D
PanelView Plus 600
• 2711PC-K4M20D, 2711PC-B4C20D,
• 2711PC-T6M20D, 2711PC-T6C20D,
• 2711PC-T10C4D1
PanelView Plus Compact
400, 600, 1000
TIP
All DC logic modules used by PanelView Plus 6 terminals are isolated.
Table 3 - Nonisolated DC Logic Modules
Cat. No.
(1)
(1) These logic modules support FactoryTalk View Machine Edition software, version 5.1 or earlier.
Logic Modules with Nonisolated DC Power
2711P-RP Logic module without nonvolatile memory and RAM
2711P-RP1 Logic module with 64 MB nonvolatile memory and RAM
2711P-RP2 Logic module with 128 MB nonvolatile memory and RAM
2711P-RP6 CE logic module with 128 MB nonvolatile memory and RAM
2711P-RP2K Conformal-coated logic module with 128 MB nonvolatile memory and RAM
2711P-RP6K CE conformal-coated logic module with 128 MB nonvolatile memory and RAM
2711P-RP3 Logic module with 256 MB nonvolatile memory and RAM
2711P-RP7 CE logic module with 256 MB nonvolatile memory and RAM
IMPORTANT
Refer to Communication Port Isolation
on page 21 for information on
communication port isolation.
