6.2 Advanced menu:
MENU DESCRIPTION
SELECTABLE
VALUES
min-max
DEFAULT UNITS
..
Functioning of opening photocell PHOTO2
0 = Enabled in opening and closing OP/CL
1 = Enabled only in opening OP
0-1 0
..
Photocells test
0 = disabled
1 = enabled PHOTO1
2 = enabled PHOTO2
3 = enabled PHOTO1 and PHOTO2
0-3 0
..
Safety edge type
0 = contact (NC)
1 = resistive (8k2)
0-1 0
..
Operation mode of safety edge
0= working only in closing with inversion of movement
1 = stops the automation (both opening and closing) and free the obstacle (short
inversion)
0-
1 0
..
Safety edge test
0 = disabled
1 = enabled
0-1 0
..
Pedestrian opening 0-100 30 %
..
Auto reclosing time from pedestrian opening (0 = disabled) 0-900 20 s
..
Blinker output mode
0 = Fix
1 = Blinking
0-1 1
..
Pre-flashing time (0 = disabled) 0-10 0 s
..
Courtesy ligth settings
0 = At the end of movement for a TCY time
1 = On if the gate is not closed + TCY time
2 = On if courtesy light timer (TCY) not expired
3 = Open gate light on/off
4 = Open gate light with proportional flashing
0-
4 0
..
Courtesy light time 0-900 0 s
..
Dead-man
0 = disabled
1 = enabled
0-1 0
..
Setting threshold of cycles for assistance request. Once limit is reached the next
cycles will be done with fast blinking (only if  enabled) (0 = disabled)
0-
100 0
x1000
cicli
..
Continuous blinking for assistance request (done only with closed gate).
0 = disabled
1 = enabled
0-1 0
..
Water-hammer and elecrtical lock in opening phase (0 = disabled) 0-100 0
x100
ms
..
Water-hammer in closing phase (0 = disabled) 0-100 0
x100
ms
..
Time of pressure in closed for hydraulic motors (0 = disabled) 0-480 0 minuti
..
Restore default settings, enter to modify the parameter and then keep pressed the
MENU button, a count down appears that ends with  on the display
..
Cancelling all transmitters, enter to modify the parameter and then keep pressed
the MENU button, a count down appears that ends with  on the display

Viewing of the memory location for a single transmitter 0-999

Cancellation of a single transmitter 0-999
