32-EN
Specifications
FM TUNER SECTION
MW TUNER SECTION
LW TUNER SECTION
CD PLAYER SECTION
USB SECTION
BLUETOOTH SECTION (CDE-103BT/CDE-104BTi only)
PICKUP
GENERAL
CHASSIS SIZE
NOSEPIECE SIZE
• Due to continuous product improvement, specifications and design
are subject to change without notice.
CAUTION
Tuning Range 87.5-108.0 MHz
Mono Usable Sensitivity 0.7 µV
Alternate Channel Selectivity 80 dB
Signal-to-Noise Ratio 65 dB
Stereo Separation 35 dB
Capture Ratio 2.0 dB
Tuning Range 531-1,602 kHz
Sensitivity (IEC Standard) 25.1 µV/28 dB
Tuning Range 153-281 kHz
Sensitivity (IEC Standard) 31.6 µV/30 dB
Frequency Response 5-20,000 Hz (±1 dB)
Wow & Flutter (% WRMS) Below measurable limits
Total Harmonic Distortion 0.008% (at 1 kHz)
Dynamic Range 95 dB (at 1 kHz)
Signal-to-Noise Ratio 105 dB
Channel Separation 85 dB (at 1 kHz)
USB requirements USB 1.1/2.0
Max. Power Consumption 500 mA
USB Class Mass Storage
File System FAT 12/16/32
MP3 Decoding MPEG-1/2 AUDIO Layer-3
WMA Decoding Windows Media™ Audio
AAC Decoding AAC-LC format “.m4a” file
Number of Channels 2-Channel (Stereo)
Frequency Response* 5-20,000 Hz (±1 dB)
Total Harmonic Distortion 0.008% (at 1 kHz)
Dynamic Range 95 dB (at 1 kHz)
Signal-to-Noise Ratio 105 dB
Channel Separation 85 dB (at 1 kHz)
* Frequency response may differ depending on the encoder
software/bit rate.
Bluetooth Specification Bluetooth V2.0
Output Power +4 dBm Max. (Power class 2)
HFP (Hands-Free Profile)
HSP (Head Set Profile)
Wave length 795 nm
Laser power CLASS I
Power Requirement 14.4 V DC
(11-16 V allowable)
Maximum Power Output 50 W × 4
Maximum Pre-Output Voltage 2 V/10 k ohms
Bass ±14 dB at 60 Hz
Treble ±14 dB at 10 kHz
Weight 1.5 kg (3 lbs. 4 oz)
Width 178 mm (7")
Height 50 mm (2")
Depth 161 mm (6-3/8")
Width 170 mm (6-3/4")
Height 46 mm (1-13/16")
Depth 25 mm (1")
CLASS 1
LASER PRODUCT
(Bottom side of player)
