17
PARTS LIST
#800000 CLASSIC PARTS LIST- AMI0070505 TO PRESENT
Part# Description Qty/Unit
1035 Jackshaft bushing 1
1040 Retainer snap ring 2
1069 Washer .65 ID .88 OD shim 4
1132 Key woodruff 1
1184 Screw 1/4-20 x .50 truss 2
1189 Washer .38 ID .75 OD cone lock 2
1192 Washer .281 ID .63 OD .06 flat 10
1253 Nut 5/16-18 hex 1
1270 Washer .39 ID .75 OD nylon 1
1271 Drive chain (68 link) 1
1272 Belt gear type 1
1344 Screw 1/4-20 x 1.50 hex 4
1450 Screw 5/16-18 x 2.50 hex 1
1872 Pulley driven 1
1963 Wire loom .437 ID 10”
2236 Screw 3/8-24 x 3.75 hex 1
2237 Nut 3/8-24 hex 1
2244 Jackshaft & sprocket (13 tooth) 1
2410 Cord AC 1
2415 Pin .125 x .625 roll 3
3083 Nut 1/4-20 serrated flanged 6
3536 Pulley motor 1
3690 Label patent 1
4075 Screw 1/4-20 x 2.00 FHCS 2
4790 Wheel 6” w/ bearing 2
5190 Screw 1/4-28 x .75 SHCS 1
5560 Nut 3/8-16 hex nylon jam 1
6880 Boot lower seat post 1
7281 Screw 1/4-20 x .88 SHCS 2
7657 Screw #10-24 x .38 self tap 1
7834 Label AMI serial number 3
7837 Label moving parts warning 1
8458 Screw 1/4-20 x 1.50 button 4
Part# Description Qty/Unit
8675 Ground wire asm 1
9357 Wheel housing blue 1
9704 Charger 1.5 amp 24 volt 1
9751 Battery 7 AH w/ label 2
9936 Handle upper 1
9950 Lever handle adjustment 1
10050 Bearing set 1
10144 Wire asm battery to controller 1
10200C Controller enclosure asm Classic 1
10341 Plug finish 1.62 ID 2
10391 Motor 24V DC 1
10402 Fork weldment 1
10534 Clamp nylon cable black 1
10586.21 Column asm blue EZ Tilt handle 1
10610 Grommet 7/8” groove dia. 5/8 ID 1
10691 Wheel & sprocket asm 1
10766 Platform weldment Classic 1
10767 Battery case assembly Classic 1
10772 Battery case bracket 1
10773 Mat Classic 1
10774 Spring brake lever 1
10775 Lever brake 1
10776 Bracket weldment brake shaft 1
10777 Spring take-apart lever 1
10778 Pouch removable 1
10779 Lever platform take-apart 1
10780 Seat Black value padded 1
10782 Seat post assembly upper Classic 1
10785 Wedge brake 1
10786 Cap brake lever 1
267000 Seat lock asm RH 1
267001 Stem collar with screw & nut 1
300265 Seat post lower (includes fasteners) 1
